OEM-B242

0.1-600rpm

0.0053-3100mL/min

Optional pump head：

EasyPump

Online consultation

Download

Product Introduction

4 rollers, low pulsation, high precision.
The tube clamp linkage mechanism makes it more convenient to install the tube.
The rubbing wheel adjustment mechanism can easily fix different size tube.
The lever assist mechanism makes the operation more easy.
The tube pressure gap fine-tuning mechanism can adjust the pressure, extend the life of the tube and improve the dispensing accuracy.
Two tubes can be installed at the same time to realize single pump head with two channels.

Motor type	Stepper motor
Display	Industrial grade 4.3" LCD color display
Control method	Touch screen and Mechanical keypad
Speed range	≤600rpm
Max.flow rate	3100mL/min
Function type	OEM-B242, Flow rate type OEM-B243, Dispensingtype OEM-B244, Multichannel filling type
Working environment	0-40°C, <80%RH

Pump Head	Tubing	lDxWall thickness(mm)	mL/r	Flow Rate(mL/min) (0.1-600rpm)	Tubing Max.Pressure(Mpa)		Weight(kg)
Pump Head	Tubing	lDxWall thickness(mm)	mL/r	Flow Rate(mL/min) (0.1-600rpm)	Intermittent	Continuous	Weight(kg)
Single Channel EasyPump I/III	13#	0.8x1.6	0.053	0.0053-32	0.27	0.17	0.6
	14#	1.6x1.6	0.27	0.027-162
	19#	2.4x1.6	0.55	0.055-330
	16#	3.2x1.6	0.933	0.0933-560
	25#	4.8x1.6	1.967	0.1967-1180	0.24	0.14
	17#	6.4x1.6	3.333	0.3333-2000	0.14	0.10
	18#	7.9x1.6	4.3	0.43-2580	0.10	0.07
Single Channel EasyPump II/IV	15#	4.8x2.4	1.8	0.18-1080	0.27	0.17
	24#	6.4x2.4	2.733	0.2733-1640	0.27	0.17
	35#	7.9x2.4	3.833	0.3833-2300	0.24	0.14
	36#	9.6x2.4	5.167	0.5167-3100	0.24	0.14
Dual Channel EasyPump V/VI	13#	0.8x1.6	0.053	0.0053-32	0.27	0.17
	14#	1.6x1.6	0.27	0.027-162
	19#	2.4x1.6	0.55	0.055-330
	16#	3.2x1.6	0.933	0.0933-560
	25#	4.8x1.6	1.967	0.1967-1180	0.24	0.14
