- Compact design suitable for supporting a variety of instruments.
- Single and dual channels for option.
- Accepts many different tubes.
| Pump Head | Tubing | IDxWallthickness(mm) | Speed(rpm) | Flow rate(mL/min) |
| MiniPump01 / MiniPump01(PVDF) |
1*1.1 | 1x1.1 | 0.1-300 | 0.005-15.01 |
| 2*1 | 2x1 | 0.018-54.63 | ||
| 2.5*1 | 2.5x1 | 0.0256-76.84 | ||
| 3*1 | 3x1 | 0.0356-108.39 | ||
| 13# | 0.8x1.6 | 0.0024-8.28 | ||
| 14# | 1.6x1.6 | 0.0112-33.88 | ||
| 19# | 2.4x1.6 | 0.0252-77.23 | ||
| 16# | 3.1x1.6 | 0.0394-114.31 | ||
| MiniPump01 | 25# | 4.8x1.6 | 0.0652-190.00 | |
| MiniPump02 / MiniPump02(PVDF) |
1*1.1 | 1x1.1 | 0.005-15.01 | |
| 2*1 | 2x1 | 0.018-54.63 | ||
| 2.5*1 | 2.5x1 | 0.0256-76.84 | ||
| MiniPump02 | 3*1 | 3x1 | 0.0356-108.39 |
|
Motor Speed(rpm)
|
Dual Channel Flow Rate (mL/min) and Tubing (1 mm wall thickness) | |||
| ID 1mm | ID 2mm | ID 2.5mm | ID 3mm | |
| 5 | 0.25 | 0.90 | 1.28 | 1.78 |
| 10 | 0.49 | 1.84 | 2.59 | 3.52 |
| 15 | 0.74 | 2.76 | 3.85 | 5.30 |
| 25 | 1.25 | 4.57 | 6.43 | 8.80 |
| 40 | 2.00 | 7.31 | 10.25 | 14.02 |
| 50 | 2.52 | 9.14 | 12.78 | 17.47 |
| 75 | 3.76 | 13.64 | 19.04 | 26.12 |
| 100 | 5.03 | 18.17 | 25.42 | 35.34 |
| 200 | 10.12 | 36.45 | 51.27 | 71.44 |
| 250 | 12.63 | 45.75 | 64.34 | 88.35 |
| 300 | 15.01 | 54.63 | 76.84 | 108.39 |
| Motor Speed(rpm) | Single Channel Flow Rate (mL/min) and Tubing (1 mm wall thickness) | ||||
| 13# ID 0.8mm | 14#ID 1.6mm | 19#ID2.4mm | 16# ID 3.1mm | 25#ID 4.8mm | |
| 5 | 0.12 | 0.56 | 1.26 | 1.97 | 3.26 |
| 10 | 0.26 | 1.15 | 2.53 | 3.90 | 6.41 |
| 15 | 0.39 | 1.74 | 3.80 | 5.80 | 9.52 |
| 25 | 0.66 | 2.88 | 6.31 | 9.59 | 15.74 |
| 40 | 1.08 | 4.59 | 10.11 | 15.29 | 25.15 |
| 50 | 1.34 | 5.69 | 12.62 | 18.96 | 31.14 |
| 75 | 2.00 | 8.54 | 18.93 | 28.36 | 46.55 |
| 100 | 2.73 | 11.37 | 25.27 | 37.66 | 61.98 |
| 200 | 5.46 | 22.76 | 50.82 | 76.02 | 124.14 |
| 250 | 6.81 | 28.40 | 65.39 | 95.08 | 153.63 |
| 300 | 8.28 | 33.88 | 77.23 | 114.31 | 190.00 |
