- Complementary phase 304 stainless steel roller assembly, effectively reducing the fluid pulsation.
- Pump head housing material is aluminum alloy.
- Using flexible tubing cartridge, install tubing easy and fast.
- The flexible block assembly with adaptive"tubing gap" function, extend the tubing life effectively.
| Model No. | Housing Material | Tubing | Tubing Clamp Material | Flow rate (mL/min) (0.1-350rpm) |
Weight(kg) | |
| Tubing Sizes | ID×Wall thickness(mm) | |||||
| DY25 | Aluminum alloy | 15# | 4.8×2.4 | PP | 0.42-1480 | 3.2 |
| 24# | 6.4×2.4 | 0.76-2670 | ||||
| 35# | 7.9×2.4 | 1-3600 | ||||
| 36# | 9.6×2.4 | 1.24-4340 | ||||
Pharmacy machine，Dispensing machine.
Tubing Installation Demonstration
