- YZ35-II pump head housing is produced with high-pressure die-casting aluminum, ensuring high strength and good consistency.
- Equipped with a standard electromagnetic sensor that outputs a cover-open to stop signal to enable the cover-open to stop function.
- The optimized tubing clamp structure allows for easy installation and removal of the tubing, preventing abnormal damage to the tubing.
- Added a lever limiter to securely fix the lever, preventing loosening due to vibrations.
- 304 stainless steel roller assembly, resistant to liquid leakage and corrosion.
| Pump Head |
Tubing | ID×Wall thickness (mm) |
mL/r | Flow rate(mL/min) (0.1-600rpm) |
Tubing pressure resistance(Mpa) | Material | Weight(kg) | |
| Continuous | Intermittent | |||||||
| YZ35-II | 26# | 6.4×3.3 | 6.9 | 0.69-4200 | 0.27 | 0.2 | Cast aluminum alloy | 2.8 |
| 73# | 9.6×3.3 | 12.3 | 1.23-7400 | 0.27 | 0.2 | |||
| 82# | 12.7×3.3 | 20 | 2-12000 | 0.14 | 0.1 | |||
Tubing Installation Demonstration
