- 4rollers, low pulsation, high precision.
- The tube clamp linkage mechanism makes it more convenient to install the tube.
- The rubbing wheel adjustment mechanism can easily fix different size tube.
- The lever assist mechanism makes the operation more easy.
- The tube pressure gap fine-tuning mechanism can adjust the pressure, extend the life of the tube and improve the dispensing accuracy.
- Two tubes can be installed at the same time to realize single pump head with two channels.
| Pump Head | Tubing | lDxWall thickness(mm) |
mL/r | Flow Rate(mL/min) (0.1-430rpm) |
Tubing Max.Pressure(Mpa) | Weight(kg) | |
| Intermittent | Continuous | ||||||
| Single Channel EasyPump I/III |
13# | 0.8x1.6 | 0.053 | 0.0053-22.79 | 0.27 | 0.17 | 0.6 |
| 14# | 1.6x1.6 | 0.27 | 0.027-116.1 | ||||
| 19# | 2.4x1.6 | 0.55 | 0.055-236.5 | ||||
| 16# | 3.2x1.6 | 0.933 | 0.093-401.19 | ||||
| 25# | 4.8x1.6 | 1.967 | 0.197-845.81 | 0.24 | 0.14 | ||
| 17# | 6.4x1.6 | 3.333 | 0.333-1433.19 | 0.14 | 0.10 | ||
| 18# | 7.9x1.6 | 4.3 | 0.430-1849 | 0.10 | 0.07 | ||
| Single Channel EasyPump II/IV |
15# | 4.8x2.4 | 1.8 | 0.180-774 | 0.27 | 0.17 | |
| 24# | 6.4x2.4 | 2.733 | 0.273-1175.19 | ||||
| 35# | 7.9x2.4 | 3.833 | 0.383-1648.19 | 0.24 | 0.14 | ||
| 36# | 9.6x2.4 | 5.167 | 0.517-2221.81 | ||||
| Dual Channel EasyPump V/VI |
13# | 0.8x1.6 | 0.053 | 0.0053-22.79 | 0.27 | 0.17 | |
| 14# | 1.6x1.6 | 0.27 | 0.027-116.1 | ||||
| 19# | 2.4x1.6 | 0.55 | 0.055-236.5 | ||||
| 16# | 3.2x1.6 | 0.933 | 0.093-401.19 | ||||
| 25# | 4.8x1.6 | 1.967 | 0.197-845.81 | 0.24 | 0.14 | ||
