- Change the tubing easily and rapidly.
- Two kinds of material housing for option: PPS and PSF.
- High precision and high rigidity.
- 3 rollers and 6 rollers for option.
- 304/316 stainless steel roller material resists corrosion.
| Model No. | Tubing | ID×Wall thickness (mm) |
mL/rpm | (0.1-600rpm) Flow rate (mL/min) |
Tubing max pressure Mpa | Material & Weight(kg) | ||
| Intermittent | Continous | PSF | PPS | |||||
| YZ1515x | 13# | 0.8×1.6 | 0.07 | 0.07-42 | 0.27 | 0.17 | 0.40 （three rollers） 0.44 （six rollers） |
0.46 （three rollers） 0.50 （six rollers） |
| 14# | 1.6×1.6 | 0.27 | 0.27-162 | |||||
| 19# | 2.4×1.6 | 0.55 | 0.055-330 | |||||
| 16# | 3.1×1.6 | 0.82 | 0.082-492 | |||||
| 25# | 4.8×1.6 | 1.7 | 0.17-1020 | 0.24 | 0.14 | |||
| 17# | 6.4×1.6 | 2.9 | 0.29-1740 | 0.14 | 0.10 | |||
| 18# | 7.9×1.6 | 3.8 | 0.38-2280 | 0.10 | 0.07 | |||
| YZ2515x | 15# | 4.8×2.4 | 1.7 | 0.17-1020 | 0.27 | 0.17 | 0.40 （three rollers） |
0.46 （three rollers） |
| 24# | 6.4×2.4 | 2.9 | 0.29-1740 | |||||
